| Category | Description |
| Fiber alignment | IPAAS Core-to-Core Alignment (image pattern analysis alignment system) |
| Applicable type of fibers | 0.25mm, 0.9mm, 2.0mm, 3.0mm, 4.0, indoor cable |
| Fiber count | Single fiber |
| Applicable fiber dimensions | Cladding diameter: 80~150㎛, Coating diameter: 100㎛~4mm |
| Fiber setting and cleaved length | 0.28in ~ 0.63in |
| Splicing modes | Splice mode: 300, Heat mode: 100 |
| Typical splice loss | SM: 0.02dB, MM: 0.01dB, DS: 0.04dB, NZDS: 0.04dB |
| Return loss | > 60dB (typical) |
| Splicing time | Typical 6 sec. (quick mode) |
| Sleeve heating time | 9sec (IS-45 Sleeve, IS-45 mode), 13sec (IS-60 Sleeve, IS-60 mode) |
| Applicable protection sleeve | 1.5in, 2.4in, 1.3in or 1.1in for SOC |
| Storage of splice result | The last 10,000 results to be stored in the internal memory (image 10,000 results) |
| Tension test | 1.96N ~ 2.25N |
| Operating condition | Altitude: 5,000m above sea level, Temperature: -14F ~122 F, Humidity: 0~95%,Wind: 15m/s, non-condensing, dust proof, water proof, shock proof |
| Storage condition | Temperature: -40℉ ~176 F Humidity: 0~95% |
| Dimension | 5.6(W) x 6.4(L) x 5.5(H)in (without bumper) |
| Weight | With battery 5.0lb |
| Viewing method and display | Two CMOS cameras and 5.0-inch color touch LCD |
| Fiber view and magnification | X/Y: 200X, Max: 400X |
| Power supply | DC Lithium polymer battery (DC 14.8V, 4700, 6000mAh-option), 100~240V AC charger |
| No. of splice cycles with battery | Typical 250 cycles / More than 350 cycles (K11-6000) |
| Electrode life | More than 3,500 times |
| Terminals | USB |
