| Category | Description |
| Fiber alignment | IPAAS clad to clad alignment |
| Applicable type of fibers | 0.25mm, 0.9mm, 2.0mm, 3.0mm Indoor cable |
| Fiber count | Single fiber |
| Applicable fiber dimensions | Cladding diameter: 125μm, Coating diameter: 150μm~3mm |
| Fiber setting and cleaved length | 7mm to 16mm (0.28in to 0.63in) |
| Splicing modes | Splice mode: 300, Heat mode: 100 |
| Typical splice loss | SM: 0.02dB, MM: 0.01dB, DS:0.04dB, NZDS: 0.04dB |
| Return loss | > 60dB |
| Splicing time | Typical 7 sec. with SM |
| Sleeve heating time | Typical 13 sec with IS-60 mode, IS-60 sleeve |
| Applicable protection sleeve | 40mm (2.4in), 60mm(1.5in) micro sleeve |
| Storage of splice result | Data: up to 5,000 ea, Image: up to 5,000 ea |
| Tension test | 1.96N to 2.25N |
| Operating condition | Altitude: 0~5,000m above sea level, Temperature: 14°F~122°F, Humidity: 0~95%, Wind: 15m/s, non-condensing, dust proof, water proof, shock proof |
| Storage condition | Temperature: 40ºC~80ºC (-40ºF~176ºF); Humidity: 0-95% |
| Dimension | 132(W) x 212(L) x 73(H)mm (without rubber protector) |
| Weight | 1.5kg (including battery) |
| Viewing method and display | 2 AXIS CMOS cameras with 109mm (4.3in) color LCD monitor |
| Fiber view and magnification | X/Y: 110X , Max: 220X |
| Power supply | Li-ion Battery(DC 14.8V, 3400mAh), 100 ~ 240V AC charger |
| No. of splice cycles with battery | Typical 200 cycles |
| Electrode life | UP to 38,000 splices |
| Blade Life | Up to 77,000 cleaves |
| Terminals | USB |
